ICU,CCU,HDU Solution
Biphasic Defibrillator with AED
- The DM7000 defibrillator is a compact, multi‑function biphasic device offering AED, manual, monitoring, and pacing modes with selectable 2–360J energy and fast charging for emergency and hospital use.
- What the DM7000 Is
- The DM7000 is a clinical defibrillation system designed for Basic Life Support (BLS) and Advanced Cardiac Life Support (ACLS), combining defibrillation, ECG monitoring, AED analysis, and optional SpO₂/NIBP/ETCO₂ modules
Price
Call for Price
Contact us for latest pricing and bulk discounts.
Product: Defibrillator Monitor
Brand: M & B Electronics Instruments
Model: DM7000
Origin: China
Features:
– High-resolution display 7 inch Screen
– 3/5 Lead ECG Monitoring
– Biphasic waveform
– Manual and Automated Defibrillation
– 2 – 360 Joule energy range
– SpO2 function
– Rechargeable battery providing 3 hours of ECG monitoring or 100 shocks at 360j
– 50mm Thermal Printer
– Easy access user-friendly front panel
– Recessed menu buttons
Brand: M & B Electronics Instruments
Model: DM7000
Origin: China
Features:
– High-resolution display 7 inch Screen
– 3/5 Lead ECG Monitoring
– Biphasic waveform
– Manual and Automated Defibrillation
– 2 – 360 Joule energy range
– SpO2 function
– Rechargeable battery providing 3 hours of ECG monitoring or 100 shocks at 360j
– 50mm Thermal Printer
– Easy access user-friendly front panel
– Recessed menu buttons
| Display | |
| Screen Type | High-resolution display |
| Screen Size | 8 inches diagonally |
| Sweep Speed | 25mm/sec |
| Information | Heart Rate, Lead/Pads, Alarm On/Off, SpO2, AED Functions and Prompts, Alarm Selection and Limits, Delivered Energy. |
| Defibrillator | |
| Waveform | Biphasic |
| Charge Time | Less than 7 seconds with a new fully charged battery. |
| Energy Display | Monitor display indicates both selected and delivered energy. |
| Charge Prompt Type | Voice and visual prompts. |
| Electrode Impedance Measurement Range | 0-250 ohms. |
| ECG Monitoring | |
| Patient Connection | 3-lead ECG cable, or 5-lead ECG cable, paddles. |
| Lead Selection | Displayed on monitor, paddles, I, II, III, AVR, AVL, AVF, V. |
| ECG Size | 0.25, 0.5, 1, 1.5, 2, 4 cm/mV diplay on monitor. |
| Heart Rate | 20-300BPM. |
| Heart Rate Alarm | On/Off displayed on monitor, user-selectable. |
| Smart Alarms | Beeper/voice prompts indicate shockable rhythm. |
| Battary | |
| Type | Rechargeable, Ni-MH battery, 12V. |
| Operating Time | For a new, fully charged battery: 60 defibrillator discharges at maximum energy, or 3 hours minimum of continuous ECG monitoring. Additional parameters will effect operating time with different functions. |
| SpO2 Module | |
| Measurement Range | 30~100%, ±2% between 80%~90%, others ±5% |
| Alarm Range | User set high limit and low limit. |
| Alarm Accuracy | ±10% within setting values. |
| Alarm time Accuracy | less than 12 sec. |
| Recorder | |
| Paper | 50mm thermal. |
| Speed | 12.5mm/sec, 25mm/sec, 50mm/sec. User-selectable 6-second delay. |
| Printing Method | High-resolution, thermal print head. |
| Print-out Modes | Manual or automatic, user-configurable. |
| On/Off Control | Front panel and paddle. |
| Automatic Function | 9-second recording initiated by alarm activation or defibrillator charge or defibrillator discharge. |
| AED Mode | |
| AED Function | Auto analyze and charge x3 with programmable auto energy level selection, screen prompts, and voice prompts. |
| Shockable Rhythms | Ventricular fibrillation with amplitude >=200uV, ventricular tachycardia with rates >=140bpm, and QRS complex wave duration >=140ms. |
| Charge Control | Control on device front panel, press key on paddle. |
| Prompts | Voice and visual prompts. |
| Manual Mode | |
| Energy Selection | Selectable at 2, 5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, 360 joules. |
| Synchronized Mode | Synchronizes defibrillator pulse to patient’s R-wave. ”SYNC” message displayed on monitor. |
